Appearance, Color & Gradients

The Appearance section of the Design tab controls the visual style of the selected element.

Fill

The fill is the interior color of a shape, or the color of text or an icon. For shapes that support gradients (rectangle, circle, ellipse, star, polygon, triangle, curved rectangle) you can choose a solid color or a gradient.

Appearance section with the gradient picker open on the Fill control. Shows the gradient type selector (Linear/Radial), an Angle slider for direction, a list of color stops each with a position slider and a delete (trash) icon, an Add stop button, and a hex color picker for the selected stop.

Solid color picker

Click the fill swatch to open the color picker. You can:

Pick a color in the saturation/value square.
Drag the hue slider.
Type an exact hex value in the input field.

Gradient picker

For gradient-capable shapes, a toggle above the color picker lets you switch between Solid and Gradient modes. The gradient is defined by:

Type — Linear or Radial.
Angle (linear only) — a single slider from 0° to 360° that sets the gradient direction.
Color stops — a list of stops, each with its own color (hex picker) and a position slider (0–100%). Click Add stop to insert a new stop (it’s placed in the largest gap automatically), and use the trash icon on a row to delete that stop.

Radial gradient: A circular gradient emanating from a center point; set its stops the same way (the Angle slider doesn’t apply).

Stroke / Border

A stroke (border) draws a line along the element’s edge.

Control	Description
Stroke color	Color swatch (same picker as fill)
Stroke width	Width in px (0–50); set to 0 to remove

For line and arrow elements the stroke IS the element — the controls are labeled Color and Thickness instead.

Opacity

A slider from 0% (fully transparent) to 100% (fully opaque). Affects the entire element including any stroke.

Corner Radius

Available on rectangles, curved rectangles, and image elements. Rounds the corners. Enter a value in px, or use a large value to create a pill shape. The helper text reads: “px — use large values for pill shape.”

Shadow

The Shadow section is collapsed by default. Click to expand it.

Shadow section expanded showing Color picker, Blur field (in px), and Offset with X and Y fields.

Control	Description
Color	Shadow color (including alpha for semi-transparent shadows)
Blur	Blur radius in px (0–100)
Offset X	Horizontal shadow offset in px
Offset Y	Vertical shadow offset in px

Set Blur to 0 for a hard-edged shadow. Use negative Offset X/Y values to position the shadow to the top-left.
